P10mm RGB Outdoor LED Module

P10mm single color led display module, p10 red color led module With High Brightness, 2 Years Warranty P10 LED screen panel.

  • Pixel Pitch: 10mm
  • Module Size: 320*160mm
  • Module Resolution: 32*16
  • In Stock
  • CE,RoHS,FCC Approved
  • 2 Years Warranty

Description

160mmx160mm P10mm RGB Outdoor led module with With High Brightness and 2 Years Warranty. 16x16dots PH10mm outdoor 1R1G1B LED screen panel high waterproof IP65 outdoor DIP346 LED sign module.

LED Module Size: 160mmx160mm
LED Module Brightness: >6500 CD/m2(Nits)

Remark:

1. DIP Outdoor LED Module Including the Data & Power Cables, Waterproof Rubber Ring.

2. Epistar LEDs, 2 Years Warranty, Ship in 24 hours,Free Online Support.

3. LED Module Can Work With Linsn,Novastar,Colorlight,Xixun LED Conrol Card Etc.

P10mm RGB LED Display Module Parameters:

LED Module:
Pixel Pitch: 10mm DIP LED
Module Size: 160mmx160mm
Module Resolution: 16×16 dots
Driver Mode 1/4 Scan
Warranty Time: 2 Years
Certificates: CE,RoHS
Electricity Parameter:
Physical density: 10000 pixels/m2
Brightness: 6500 – 6800 nits
Brightness adjusted: 100 grade by software, or by Auto-optic induced
Best view distance: ≥ 6m
Best view angle: Horizontal ±110°, Vertical ±110°
Color processing: 16bit
Color temperature(k): 5000 — 9500 (choice by user)
Whole display flatness: ≤ 1mm juncture
Working temperature: -20°C ~ +50°C
Refresh frequency: ≥ 300Hz
Humidity(RH): ≤ 90 ~ 95%
Protection grade: IP65 Waterproof
Working Voltage: DC 5V
Power supply: AC 110 / 220V, 50/60Hz
Average power consumption: 550 w/m2
Max power consumption: 800 w/m2
Screen lifetime: 100000 hours



LED Display Module Aging & Testing

LED Display Module aging and testing is refers to imitate the long time operation without working problems,it is the most important to ensure the reliability of the LED display. LED display can be more stable after aging, and it can help the use of the efficiency. led screen aging test is a very important link in quality control.
LED display module aging test

The LED aging test is based on the product’s failure rate curve, which is the characteristics of the bathtub curve, and the countermeasures are adopted to improve the reliability of the product.The indoor led module aging method includes constant current aging and constant pressure aging. A constant current source is that the current is constant at any time. The frequency is not constant. That’s communication or pulsating current. The communication or pulsating current source can be described as the effective value stable, but this power supply cannot be called “constant current source”.Constant current aging is the most consistent feature of LED current operation and is the most scientific method for the aging of LED displays. Over current impact aging and manufacturers the latest clothing design school chooses an aging technique, after using the frequency adjustable, current adjustable constant current source for such aging, in order to judging the quality of the outdoor led module in a short time and can pick out the dangerous LEDs make sure the led display module working well after installation.

LED display module Aging test

The aging of LED display is divided into white balance aging (2×24 hours) and video aging (24 hours).totally 72 hours before packing.

Aging test process of led display screen:

  1. Check the led display module to install all correct.
  2. Check whether there is a short circuit or not.
  3. Check whether the module is flat and neat.
  4. Check whether the appearance is intact or not.
  5. Use the online led control system to light up.

Make sure the testing time is continuously light for more than 72 hours

LED display module Panel

After the aging test, please check the quality control group for parameters.Test content: white balance, red, green, blue,gray gradient,video effect,text effect.after 72 hours aging test,the problem should be reported to the manager of the engineering department in a timely manner.replace or repair the broken leds. making sure all parts will be working well stably before packing.
