Indoor P3mm SMD LED Module 64x64dots

  • Pixel Pitch: 3mm
  • Module Size: 192*192mm
  • Module Resolution: 64*64
  • In Stock
  • CE,RoHS,FCC Approved
  • 2 Years Warranty
Send Inquiry Now?
Have Tech Question?

Description

PH3mm SMD Indoor LED Display Module P3mm LED Screen Panel with 64X64dots pixels and 192mmx192mm size.

Remark:

1. LED Module Including the Data & Power Cables.

2. Epistar LEDs, 2 Years Warranty, Ship in 24 hours,Free Online Support.

3. LED Module Can Work With Linsn,Novastar,Colorlight,Xixun LED Conrol Card Etc.

P3mm indoor LED display module Specification:

Model UNIT-P3-I-64X64
1.LED
LED displya module LED Lamp
Color Package Intensity View Angle Wavelength Test Cond.
Red SMD 2121 150mcd 140/140 620nm 25℃,20mA
Green SMD 2121 400mcd 140/140 520nm 25℃,20mA
Blue SMD 2121 100mcd 140/140 470nm 25℃,20mA
Resolution 64(H)×64(V)
Pitch 3mm
Density 111,111 pixels/㎡
LED Arrangement SMD2121
Driver Mode Dynamic 1/16 Duty constant current
Size 192mm×192mm
Mask Pure Black mask-high contrast screen
3.Electricity Parameter
Optical Ratings
Brightness ≥1000cd/㎡
View Angle 140 degree ( horizontal)  140degree(vertical)
View Distance 3m-30m
Gray Scale 8bits input, correction with 16bits
Display Color 16.7M
Brightness Adjustment 100 levels
Power Supply
Operation Power AC100-240V 50-60HZ  Switch-able
Maxim Power Consumption 900 W/m2
Average Power Consumption 500 W/m2
Control System
Correction Scale Level 16bits
Frame Update Frequency 60Hz
Screen Refresh Frequency 480Hz
Gamma Correction -5.0—5.0
Support Input Composite Video, S-Video, DVI, HDMI., SDI, HD_SDI
Control Distance Ethernet cable 100m, optical fiber 5km
Support VGA Mode 800×600,1024×768,1280×1024,1600×1200
Color Temperature 5000-9300 adjustable
Brightness Correction dot by dot, module by module, cabinet by cabinet
Reliability
Operating Temp. -20-60 Celsius degree
Operating Humidity 10-95% RH
Operating Life 100,000 hours
MTBF 5000 hours
Continuous Working Time ≥48 hours
Protection Level IP54
Out of Control Pixel Rate 0.01%
